Climate C

Climate Test Chambers, series C

The latest generation with innovative technique and future-oriented design.
In the CTS climatic test cabinets, not only the temperature but also the humidity stress factor can be simulated. The humidity is measured with a capacitive sensor which stands out for its high precision, lack of maintenance and long-term stability. Here too, the advantages of the above-described CTS temperature test cabinets are of course valid.



Basic Equipment:

  • capacitive Multi-Touch-Display in the front
  • service-friendly capacitive humidity measurement system
  • defined keys for elementary functions of the installation such as
      start/stop, fixed-value/automatic operation, interruption, light, etc.
  • USB-Connection to save measuring data on USB Stick
  • Ethernet-Interface
  • 2 digital Out, to switch test specimen ON/OFF
  • adjustable software-temperature-limiter min./max.
  • shelf, stainless steel
  • entry port Ø 50 mm on the right side
  • single-hand operated door handle, lockable



Your benefits:

  • low consumption data
  • minimum noise level
  • user-friendly operation and programming
  • uniform operation due to identical Multi-Touch-Display
      for all chamber sizes
  • demineralized water system with level indicator
  • temperature measuring with Pt 100 in air inlet and air outlet
  • service-friendly construction
  • international standards are fulfilled (CE-Conformity)



Test space capacity in litres:

  • 100 / 200 / 350 / 600 / 1000 / 1500 / 2000



Temperature range:

  • +10 °C+180 °C
  • -20 °C / +180 °C
  • -40 °C +180 °C
  • -70 °C / +180 °C

Humidity range:

  • 10 - 98 % RH



Design:

Control               : Multi-Touch-Display with integrated program controller

Test space         : stainless steel grade 1.4301

Refrigerants       : environmental friendly refrigerants

Humidity system: capacitive measuring



Options:

  • entry ports Ø 50 mm, 80 mm and 125 mm
  • shelves
  • panoramic window, multiple glazed sized 570 x 710 mm, > 200 ltr.,
      incl.
    LED-Light
  • hand-holes in the door
  • Pt 100 for temperature measuring on test specimen reversible
      to controller function
  • air dryer system
  • mobile design
  • temperature protection for test specimen
  • water cooled refrigeration unit
  • CID software for programming and documentation
  • variable air speed in the test space
  • notch Lead-through
  • Other interfaces: RS232, RS485 and USB
