Stress Screening TS/CS

Temperature and Climate Stress Screening Chambers series TS/CS

The CTS temperature/climatic stress screening test cabinets can achieve high change rates of up to 30 K/min. with conventional cooling technology thanks to amplified compressors and a strong fan capacity. By this means, CTS offers optimized output with low consumption figures and attractive prices. Thus, the limits of your test item can be determined more quickly. Faster change rates are optionally possible using nitrogen.


Basic Equipment:

  • capacitive Multi-Touch-Display in the front
  • service-friendly capacitive humidity measurement system
  • defined keys for elementary functions of the installation such as
      start/stop, fixed-value/automatic operation, interruption, light, etc.
  • USB-Connection to save measuring data on USB Stick
  • Ethernet-Interface
  • 2 digital Out, to switch test specimen ON/OFF
  • adjustable software-temperature-limiter min./max.
  • shelf, stainless steel
  • entry port Ø 50 mm on the right side
  • single-hand operated door handle, lockable



Your benefits:

  • low consumption data
  • minimum noise level
  • extremely high temperature change rates
  • user-friendly operation and programming
  • uniform operation due to identical Multi-Touch-Display
      for all chamber sizes
  • demineralized water system with level indicator
  • temperature measuring with Pt 100 in air inlet and air outlet
  • service-friendly construction
  • international standards are fulfilled (CE-Conformity)


Temperature change rates:

  • 5 K/min, 10 K/min und 15 K/min



Test space capacity in litres:

  • 100 / 200 / 350 / 600 / 1000 / 1500 / 2000



Temperature range:

  • - 40 °C+180 °C
  • - 70 °C+180 °C


Design:

Control                         : Multi-Touch-Display with integrated program controller

Test space                   : stainless steel grade 1.4301

Refrigerants                 : environmental friendly refrigerants

Humidity system (type CS): capacitive measuring

Options:

  • Entry ports Ø 50 mm, 80 mm und 125 mm
  • shelves
  • panoramic window, multiple glazed, sized 570 x 710 mm, < 200 ltr.,
      incl.
    LED-light
  • hand-holes in the door
  • Pt 100 for temperature measuring on test specimen reversible
      to controller function
  • air dryer system
  • mobile design
  • air/water cooled refrigeration unit
  • temperature protection for test specimen
  • CID software for programming and documentation
  • variable air speed in the test space
  • notch Lead-through
  • Other interfaces: RS232, RS485 and USB
